Sportster Car Trailer (Mid-Range Car Trailer)
Standard Features
- 205/75R15 C Range Tires
- White Spoke Wheels – Bolt Pattern 5 – 4 1/2
- A-Frame Tongue w/Safety Chains and Hooks
- Genuine Dexter Spring Axles w/E-Z Lube Hubs
- Forward Self Adjusting Electric Brakes w/Breakaway Kit & Charger
- 2 5/16″ Coupler/Hitch Ball Size
- 7 Pole Light Plug Connector
- Hitch Height: 21″ – Platform Height: 22″
- 2000# Tongue Jack
- 3/8″ Plywood Walls – 16″ OC
- .030 Exterior Aluminum – White & Black (Colors Optional)
- .032 Seamless 1 pc. Aluminum Roof – LIFETIME WARRANTY
- Steel Hat Channel Roof Bows – 24″ OC
- 3/4″ Plywood Floor – Unpainted – LIFETIME WARRANTY
- 4″ Formed C-Channel Crossmembers – 16″ OC
- 2″ x 6″ Structural Steel Tube Frame
- Aluminum Diamond Plate Corners
- 16″ Aluminum Diamond Plate Front Stone Guard
- Smooth Aluminum Fender Flares
- Hot Dipped Galvanized Door Hardware
- LED Lighting – LIFETIME WARRANTY
Trailer Dimensions
Specifications
| Size | 8.5' X 20' |
|---|---|
| Model # | CM820E-CT |
| GVWR | 7000# GVWR - (2) 3500# Dexter Spring Axles |
| Overall Exterior Length | 23' 6" |
| Overall Exterior Height | 103" |
| Overall Exterior Width | 102" |
| Interior Box Length | 19' 8" |
| Interior Box Width | 96" |
| Width Between Wheel Wells | 82" |
| Interior Height | 78 1/2" |
| Ramp Rear Door | 94" W x 75" H Opening - No Flip Out |
| Beaver Tail | 48" w/3" Drop |
| Side Man Door Size | 48" - No Inside Step |
Trailer Options
The Sportster Line has limited optional equipment which is shown below. Extra height is limited.
Color Options
Standard
Options
Request A Quote
Need a quote for a Cargo Trailer? Please click the button below and fill out the necessary information.
Please sure to know the trailer size(s), closest dealer and color option before filling out the form.
